Software User Manual D-Link Unified Access System

02/15/2011

Document 34CS3000-SWUM104-D10 Page 163

Use the buttons at the bottom of the page to perform the following tasks:

• Click Refresh to update the screen with the most current information.

• Click Submit to update the switch with the values on the screen. If you want the switch to retain the new values across

a power cycle you must perform a save.

TXOP Limit Station EDCA Parameter Only (The TXOP Limit applies only to traffic flowing from the

client station to the access point.)

The Transmission Opportunity (TXOP) is an interval of time when a WME client station

has the right to initiate transmissions onto the wireless medium (WM).

This value specifies (in milliseconds) the Transmission Opportunity (TXOP) for client

stations; that is, the interval of time when a WMM client station has the right to initiate

transmissions on the wireless network.

The TXOP Limit range is 0 to 65535. The value is in units of 32-microsecond periods.

Table 60: QoS Settings (Cont.)

Field Description
