Software User Manual D-Link Unified Access System

02/15/2011

Document 34CS3000-SWUM104-D10 Page 147

Click Refresh to update the screen with the most current information.

Viewing Associated Client VAP Status

Each AP has 8 Virtual Access Points (VAPs) per radio, and every VAP has a unique MAC address (BSSID). The VAP

Associated Client Status page shows information about the VAPs on the managed AP that have associated wireless clients.

Click Refresh to update the screen with the most current information.

Viewing Associated Client Statistics

A wireless client can roam among APs without interruption in WLAN service. The D-Link Unified Switch tracks the traffic the

client sends and receives during the entire wireless session while the client roams among APs that the switch manages. The

switch stores statistics about client traffic while it is associated with a single AP as well as throughout the roaming session.

The statistics on the Association Summary page show information about the traffic a wireless client receives and transmits

while it is associated with a single AP.

Table 49: Associated Client SSID Status

Field Description

SSID Indicates the network on which the client is connected.

MAC Address The Ethernet address of client station.

Channel Indicates the operating channel for the client association.

Status Indicates whether or not the client has associated and/or authenticated. The valid values are:

• Associated - The client is current associated to the managed AP.

• Authenticated - The client is currently associated and authenticated to the managed AP.

• Disassociated - The client has disassociated from the managed AP, if the client does not

roam to another managed AP within the client roam timeout, it will be deleted.

Table 50: Associated Client VAP Status

Field Description

BSSID Indicates the Ethernet MAC address for the managed AP VAP where this client is associated.

SSID The SSID the client is using to connect to the WLAN.

AP MAC Address This field indicates the base AP Ethernet MAC address for the managed AP.

Location The descriptive location configured for the managed AP.

Radio Displays the managed AP radio interface the client is associated to and its configured mode.

Client MAC Address The Ethernet address of client station.

Tunnel IP Address If the client is using an L3 Tunnel, this field shows the IP address of the client. Otherwise, this

field is blank.

Table 51: Associated Client Association Summary Statistics

Field Description

MAC Address The Ethernet address of client station.
