• Click Refresh to update the screen with the most current information.

Viewing Detailed Associated Client Status

For each client associated with an AP that the switch manages, you can view detailed status information about the client and

its association with the access point.

Table 47 describes the information available on the Detail page for the associated client status.

Bandwidth Limit Down Shows the maximum rate at which the client receives traffic from

the AP in bits per second. The rate shown in this field is the

configured value rounded down to the nearest 64 kbps. A value of

0 means no bandwidth limiting is in effect in this direction.

Bandwidth Limit Up Shows the maximum rate at which the client transmits traffic to the

AP in bits per second. The rate shown in this field is the configured

value rounded down to the nearest 64 kbps. A value of 0 means

no bandwidth limiting is in effect in this direction.

Table 47: Detailed Associated Client Status

Field Description

MAC Address The Ethernet address of client station. To view details about a different client, select its MAC

address from the menu.

SSID Indicates the network on which the client is connected.

AP MAC Address MAC address of the AP to which this client is associated.

BSSID Indicates the Ethernet MAC address for the managed AP VAP where this client is associated.

Location Location of the AP to which this client is associated.

Status Indicates whether or not the client has associated and/or authenticated. The valid values are:

• Associated - The client is current associated to the managed AP.

• Authenticated - The client is currently associated and authenticated to the managed AP.

• Disassociated - The client has disassociated from the managed AP, if the client does not

roam to another managed AP within the client roam timeout, it will be deleted.

Radio Indicates the radio on which the client is associated.

Channel Indicates the operating channel for the client association.

VLAN If client is on a VAP using VLAN data forwarding mode, indicates the current assigned VLAN.

User Name Indicates the user name of client that have authenticated via 802.1X, clients on networks with

other security modes will not have a user name.

Transmit Data Rate Indicates the rate at which the client station is currently transmitting data.

Inactive Period For current association, period of time that the AP has not seen any traffic for the client.

Age Indicates the time in seconds since the switch has received new association data for this

client.

NetBIOS Name A unique 16-byte identifier that NetBIOS services use to identify resources on a network.

Tunnel IP Address This field is blank for all non-tunneled clients. For a tunneled client, this is the assigned tunnel

IP address.
