UNDERSTANDING THE MENU BAR OPTIONS

The following table provides an overview of the menu items available in the WLAN Visualization tool.

Table 83: WLAN Visualization Menu Bar Options

Menu Item Description

File

Force Refresh Resynchronizes the Java client application. If you edit the graph, you can force a

refresh to manually update the view.

Reconnect and Refresh Disconnects the client application from the switch and re-connects it.

Exit Exits the WLAN Visualization application.

Edit

New Graph Opens a window that allows you to create and configure a new graph, including the

name, background image, and scale factor for the graph.

Edit Graph Opens the window for an existing graph. You can change the background image or

graph scale. To change the name of the graph, you must create a new graph.

Delete Graph Deletes the active graph. When you select this item, a dialogue box appears to

confirm that you want to delete the graph.

Image Management Lists the available background images and allows you to delete any available

image.

View

Ungraphed Components Allows you to change the view of the ungraphed components in the panel on the

left:

Tab View—Shows one type of component at a time, organized by tabs.

List View—Shows all three types of components in the left panel.

Figure 101 on page 195 shows the difference between the tab view and list view.
