Software User Manual D-Link Unified Access System
02/15/2011
Document 34CS3000-SWUM104-D10 Page 205
RF Scan Sentry Channels Disabled
RF Scan Duration 10 milliseconds
Transmit Lifetime 512 milliseconds
Receive Lifetime 512 milliseconds
Channel Bandwidth 20 MHz
Maximum Clients 256
DTIM Period 10 beacons
Beacon Period 100 milliseconds
Automatic Channel Enabled
Limit Channels Disabled
Automatic Power Enabled
Initial Power 100
Antenna Diversity Primary
Fragmentation Threshold 2346 bytes
Short Retries 7
Long Retries 4
802.11n Protection Auto
Primary Channel Lower
Rate Sets
Supported (Mbps)
IEEE 802.1a: 54, 48, 36, 24, 18, 12, 9, 6
IEEE 802.1g: 54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1
IEEE 802.1b: 11, 5.5, 2, 1
Atheros Dynamic Turbo 5 GHz: 108, 96, 72, 48, 36, 24, 18, 12
Rate Sets (Mbps)
(Basic/Advertised)
IEEE 802.1a: 24, 12, 6
IEEE 802.1g: 11, 5.5, 2, 1
IEEE 802.1b: 2, 1
Atheros Dynamic Turbo 5 GHz: 48, 24, 12
Virtual Access Point and Network Settings
Status VAP0 is enabled on both radios, all other VAPs disabled
Network Name (SSID) dlink1
VLAN 1
Hide SSID Disabled
L3 Tunnel Disabled
Security Mode Open System
MAC Authentication Disabled
RADIUS IP Address Use Profile (Global)
RADIUS Accounting Disabled
Other Settings
QoS Enabled
WMM Enabled
Table 87: AP Profile Default Settings (Cont.)
Feature Default
