Software User Manual D-Link Unified Access System

02/15/2011

Document 34CS3000-SWUM104-D10 Page 149

• Click Refresh to update the screen with the most current information.

• Click Back to see the Association Summary.

The statistics on the Session Detail page show information about the traffic a wireless client receives and transmits while

it is connected to the same WLAN network shared by APs that the switch manages.

Use the buttons at the bottom of the page to perform the following tasks:

• Click Back to see the Associated Client Statistics Session Summary.

• Click Refresh to update the screen with the most current information.

VIEWING CLIENT AUTHENTICATION FAILURE STATUS

Wireless clients that fail to associate or authenticate with an AP appear in the client failure list along with the number of failed

attempts. The client might have security or authentication information that does not match the settings on the AP.

Status entries for failed clients are collected at a point in time and eventually age out. The age value for each entry shows

how long ago the switch recorded the entry. You can configure the age out time for status entries on the Administration >

Advanced Configuration > Global page. You can also manually delete status entries.

Duplicates Received Total duplicate packets received from the client station.

Table 54: Associated Client Session Detail Statistics

Field Description

MAC Address

(Menu)

Shows the MAC address of the client to which the values on the page apply.

To view details about a different associated client, select its MAC address

from the menu.

Packets Received Total packets received from the client station.

Bytes Received Total bytes received from the client station.

Packets Transmitted Total packets transmitted to the client station.

Bytes Transmitted Total bytes transmitted to the client station.

Fragments Received Total fragmented packets received from the client station.

Fragments Transmitted Total fragmented packets transmitted to the client station.

Transmit Retries Number of times transmits to client station succeeded after one or more

retries.

Transmit Retries Failed Number of times transmits to client station failed after one or more retries.

Duplicates Received Total duplicate packets received from the client station.

Table 53: Associated Client Association Detail Statistics

Field Description
