D-Link Unified Access System Software User Manual

02/15/2011

Page 186 Document 34CS3000-SWUM104-D10

To view information about the clients connected to the D-Link Unified Access System through the captive portal, click

Security > Captive Portal > Client Connection Status.

Figure 93: Client Summary

Table 77 describes the fields on the Client Summary page.

• To force the captive portal to disconnect an authenticated client, select the check box next to the client MAC address

and click Delete.

• To disconnect all clients from all captive portals, click Delete All.

• Click Refresh to update the screen with the most current information.

Click the MAC address of a client to view additional status information.

Viewing Client Detail

The Client Detail page shows detailed information about each client connected to the network through a captive portal.

Table 77: Client Summary

Field Description

Client MAC Address Identifies the MAC address of the client that has connected to the network through a captive

portal.

Client IP Address Identifies the IP address of the client. The default is 0.0.0.0.

User Displays the user name (Local, RADIUS, or Guest ID) of the connected client. The range is 1-

32 characters.

Protocol Shows the current connection protocol, which is either HTTP or HTTPS.

Verification Shows the current account type, which is Guest, Local, or RADIUS.
