SPECIFICATIONS

STANDARD ACCESSORIES

䡬 Chuck wrench (Spec. only for keyed chuck) ..... 1

Standard accessories are subject to change without notice.

OPTIONAL ACCESSORIES (sold separately)

(1) Side handle

(2) Hook

(3) Hook (A)

Optional accessories are subject to change without notice.

APPLICATIONS

䡬 Boring holes in metal, wood and plastic.

PRIOR TO OPERATION

1. Power source

Ensure that the power source to be utilized conforms

to the power requirements specified on the product

nameplate.

2. Power switch

Ensure that the power switch is in the OFF position.

If the plug is connected to a receptacle while the

power switch is in the ON position, the power tool

will start operating immediately, inviting serious

accident.

3. Extension cord

When the work area is removed from the power

source. Use an extension cord of sufficient thickness

and rated capacity. The extension cord should be

kept as short as practicable.

4. Selecting the appropriate drill bit:

䡬 When boring metal or plastic

Use ordinary metalworking drill bits.

䡬 When boring wood

Use ordinary woodworking drill bits.

However, when drilling 6.5 mm or smaller holes,

use a metalworking drill bit.

5. Mounting and dismounting of the bit

For keyed chuck (Fig. 1)

(1) Open the chuck jaws, and insert the bit into the

chuck.

(2) Place the chuck wrench in each of the three holes

in the chuck, and turn it in the clockwise direction

(viewed from the front side). Tighten securely.

(3) To remove the bit, place the chuck wrench into one

of the holes in the chuck and turn it in the

counterclockwise direction.

For keyless chuck (Fig. 2)

(1) Open the chuck jaws, and insert the bit into the

chuck.

To open the chuck jaws, hold the ring while turning

the sleeve in the counterclockwise direction (viewed

from the front side).

(2) Firmly grasp the ring and turn the sleeve in the

clockwise direction. Tighten securely.

(3) To remove the bit, firmly grasp the ring and turn

the sleeve in the counterclockwise direction.

(4) If it is hard to loosen the sleeve, fix the spindle

using the open-end wrench, hold the sleeve firmly,

and turn it in the loosening direction

(counterclockwise when viewed from the front).

(Fig. 3)

6. Check the rotational direction (Fig. 4)

The bit rotates clockwise (viewed from the rear

side) by pushing the R-side of the push button.

The L-side of the push button is pushed to turn the

bit counterclockwise.

(The

and

marks are provided on the body.)

7. Installing the side handle (Optional accessory)

A Side handle can be installed on either side of

the tool for right or left handed use.

To install the side handle, thread it into the socket

on the desired side of the gear cover and tighten

it securely. (Fig. 6)

Voltage (by areas)* (110V, 220V, 230V, 240V)

Power input 460W*

No load speed 0–2300 min

–1

Drill chuck capacity 10 mm

Steel Twist Bit 10 mm

Capacity Flat Spade Bit 25 mm

Wood

Auger Bit 16 mm

Weight (without cord) 1.3 kg

*Be sure to check the nameplate on product as it is subject to change by areas.

PRECAUTIONS ON USING DRILL

1. Wear ear protectors with impact drills.

Exposure to noise can cause hearing loss.

2. Use auxiliary handles supplied with the tool.

Loss of control can cause personal injury.

3. Hold the drill securely when using.

4. Do not wear gloves made of stuff liable to roll up

such as cotton, wool, cloth or string, etc.

5. Prior to drilling into walls, ceilings or floors, ensure

there are no electric cables or conduits inside.
