Hitachi D 10 VC 2 [6/41] English

English

8. Attaching the hook. (Optional accessory)

For hook (side-attaching) (Fig. 7)

Fix the hook firmly on the desired side of the gear

cover using M10 bolt which is supplied with hook.

For hook (A) (top-attaching) (Fig. 8)

To attach the hook (A), it is necessary to disassemble

the handle portion which covered the tool’s electrical

system. For your continued safety and electrical

shock protection, installing the hook (A) on this drill

should ONLY be performed by a Hitachi Authorized

Service Center.

CAUTION:

When the power tool is used with a hook fixed to

it, pay attention to the following points:

䡬 Before hanging the main unit from the waist belt,

make sure that the drill has come to a complete

stop.

While it is suspended from the waist belt, the power

plug must be disconnected from the power source.

䡬 Do not walk about with the power tool hanging

from the waist belt.

䡬 In the case of operation in a high place, it is

dangerous to drop the tool accidentally. If the hook

is deformed or hung from the wrong position, there

is danger that the hook will slip off and the tool

will fall.

Be careful to avoid danger.

䡬 In making a through hole, the power tool sometimes

shakes violently when the workpiece is pierced,

from example. Be careful you are not hurt by the

hook even if such situation happens.

HOW TO USE

1. Switch operation

䡬 When the trigger is depressed, the tool rotates.

When the trigger is released, the tool stops.

䡬 The rotational speed of the drill can be controlled

by varying the amount that the trigger switch is

pulled. Speed is low when the trigger switch is

pulled slightly and increases as the trigger switch

is pulled more.

䡬 The desired rotation speed can be pre-selected with

the speed control dial.

Turn the speed control dial clockwise for higher

speed and counterclockwise for lower speed.

(Fig. 5)

䡬 Pulling the trigger and pushing the stopper, it keeps

the switched-on condition which is convenient for

continuous running. When switching off, the stopper

can be disconnected by pulling the trigger again.

2. Drilling

䡬 When drilling, start the drill slowly, and gradually

increasing speed as you drill.

䡬 Always apply pressure in a straight line with the

bit. Use enough pressure to keep drilling, but do

not push hard enough to stall the motor or deflect

the bit.

䡬 To minimize stalling or breaking through the

material, reduce pressure on drill and ease the bit

through the last part of the hole.

䡬 If the drill stalls, release the trigger immediately,

remove the bit from the work and start again. Do

not click the trigger on and off in an attempt to

start a stalled drill. This can damage the drill.

䡬 The larger the drill bit diameter, the larger the

reactive force on your arm.

Be careful not to lose control of the drill because

of this reactive force.

To maintain firm control, establish a good foothold,

use side handle, hold the drill tightly with both

hands, and ensure that the drill is vertical to the

material being drilled.

MAINTENANCE AND INSPECTION

1. Inspecting the drill bits

Since use of an abraded drill bits will cause motor

malfunctioning and degraded efficiency, replace the

drill bits with a new one or resharpening without

delay when abrasion is noted.

2. Inspecting the mounting screws

Regularly inspect all mounting screws and ensure

that they are properly tightened. Should any of the

screws be loose, retighten them immediately. Failure

to do so could result in serious hazard.

3. Maintenance of the motor

The motor unit winding is the very “heart” of the

power tool. Exercise due care to ensure the winding

does not become damaged and/or wet with oil or

water.

4. Inspecting the carbon brushes

For your continued safety and electrical shock

protection, carbon brush inspection and replacement

on this tool should ONLY be performed by a Hitachi

Authorized Service Center.

5. Service parts list

A: Item No.

B: Code No.

C: No. Used

D: Remarks

CAUTION

Repair, modification and inspection of Hitachi Power

Tools must be carried out by a Hitachi Authorized

Service Center.

This Parts List will be helpful if presented with the

tool to the Hitachi Authorized Service Center when

requesting repair or other maintenance.

In the operation and maintenance of power tools,

the safety regulations and standards prescribed in

each country must be observed.

MODIFICATION

Hitachi Power Tools are constantly being improved

and modified to incorporate the latest technological

advancements.

Accordingly, some parts (i.e. code numbers and/or

design) may be changed without prior notice.

NOTE

Due to HITACHI’s continuing program of research and

development, the specifications herein are subject to

change without prior notice.
