Hitachi DV18V [6/42] English
![Hitachi DV18V [6/42] English](/views2/1003839/page6/bg6.png)
Содержание
- Dv 18v 1
- Hitachi 1
- Impact drill schlagbohrmaschine кроистко öpanavo wiertarka udarowa ütyefürogep priklepovä vrtacka darbeli matkap ударная дрель 1
- English 5
- General operational precautions 5
- Precautions on using impact drill 5
- Appucations 6
- English 6
- Optional accessories sold separately 6
- Prior to operation 6
- Specifications 6
- Standard accessories 6
- English 7
- How to use 7
- Maintenance and inspection 7
- English 8
- Allgemeine vorsichtsmassnahmen 9
- Deutsch 9
- Vorsichtsmassnahmen für die benutzung der schlagbohrmaschine 9
- Anwendungen 10
- Deutsch 10
- Sonderzubehör separat zu beziehen 10
- Standardzubehör 10
- Technische daten 10
- Vor inbetriebnahme 10
- Deutsch 11
- Verwendung 11
- Wartung und inspektion 11
- Deutsch 12
- Information über betriebslärm und vibration 12
- Eaarjvikà 13
- Renika метра а2фале1а1 ката th ле1т0урпа 13
- Eaaqvikà 14
- F1pin th aeitoypria 14
- Kanonika eeapthmata 14
- Nwaoúvtai çexwpioró 14
- Texnika xapakthpiztika 14
- Ефармоге2 14
- Проа1рет1ка eeapthmata 14
- Профулакпка метра па thn xphsh toy kpoystikoy apananoy 14
- Dniabyyb 15
- Siszhiouoiailzhdx 01 vn zuu 15
- Z0xj3v3 iv hzhdhlnaz 16
- Рьильууз 16
- Podstawowe srodki ostroznosci 17
- Polski 17
- Srodki ostroznosci stosowane przy uzywaniu mtotowiertarki 17
- Dane techniczne 18
- Polski 18
- Przed uzyciem 18
- Wyposazenie dodatkowe sprzedawane oddzielnie 18
- Wyposazenie standardowe 18
- Zastosowanie 18
- Jak uzywaó mtotowiertarki 19
- Konserwacje i przeglady 19
- Polski 19
- Polski 20
- Az ütvefùrôgép hasznâlatâval kapcsolatos elóvigyàzatossàgi intézkedések 21
- Magyar 21
- Àltalànos biztonsàgtechnikai elòìràsok 21
- Felhasználási területek 22
- Magyar 22
- Müszaki adatok 22
- Standard tartozékok 22
- Választható tartozékok külôn megrendelésre 22
- Üzembehelyezés elótti tennivalók 22
- Ellenôrzés és karbantartás 23
- Használat 23
- Magyar 23
- Magyar 24
- Cestina 25
- Opatrnost pri pouzìvànl prìklepové vrtacky 25
- Vseobecné provoznì pokyny 25
- Cestina 26
- Pouzitì 26
- Pred pouzitìm 26
- Standardnì prìslusenstvi 26
- Technic kéùdaje 26
- Volitelné prìslusenstvi prodévé se zvlast 26
- Cestina 27
- Jak pouzìvat prìklepovou vrtaòku 27
- Údrzbaakontrola 27
- Darbeli matkabi kullanirken alinacak önlemler 28
- Kullanimla ìlgìlì genel önlemler 28
- Türkge 28
- Standart aksesuarlar 29
- Stege bagli aksesuarlar ayn saillir 29
- Türkçe 29
- Uygulamalar 29
- Ìslemden önce 29
- Özellikler 29
- Bakim ve gözden geçîrme 30
- Ikasyon 30
- Kullanim 30
- Türkçe 30
- Türkçe 31
- Меры предосторожности при использовании ударной дрели 32
- Русский 32
- Дополнительные принадлежности продаются отдельно 33
- Область применения 33
- Подготовка к эксплуатации 33
- Русский 33
- Стандартные принадлежности 33
- Характеристики 33
- Как пользоваться 34
- Обслуживание и проверка 34
- Русский 34
- Русский 35
- Eaaqvikö 1 37
- Garantieschein 37
- Garantì sertìfikasi 37
- Guarantee certif1cate garancia bizonylat 37
- Gwarancja 37
- Niztonoihtiko erryhshs 37
- Zârucnî ust 37
- Гарантийный сертификат 37
- Hitachi 38
- Hitachi koki 38
- Hitachi koki co ltd 42
- Hitachi koki со ltd 42
- Hitachi power tools europe gmbh 42
Похожие устройства
- Behringer UB 502 Инструкция по эксплуатации
- Clarion VMA573 Инструкция по эксплуатации
- Sharp R-770B Инструкция по эксплуатации
- Mystery MX-305 Инструкция по эксплуатации
- Indesit BA 16 FNF Инструкция по эксплуатации
- AEG SB 22 2E 411030 Инструкция по эксплуатации
- Behringer UB1832FX-PRO Инструкция по эксплуатации
- Sharp R-757H Инструкция по эксплуатации
- Clarion VRX578RUSB Инструкция по эксплуатации
- Indesit B 20 FNF Инструкция по эксплуатации
- Bosch GSB 16 RE 0.601.14E.500 Инструкция по эксплуатации
- Behringer UB2222FX-PRO Инструкция по эксплуатации
- Sharp R-6781J Инструкция по эксплуатации
- Clarion VRX878RVD Инструкция по эксплуатации
- Beko CSK 32000 Инструкция по эксплуатации
- AEG 412681(SBE 570 R) Инструкция по эксплуатации
- Behringer UB2442FX-PRO EURORACK Инструкция по эксплуатации
- Bosch SPV40E00RU Инструкция по эксплуатации
- Mystery CHAMELEON Z-9 Инструкция по эксплуатации
- Sharp R-65STR Инструкция по эксплуатации
English SPECIFICATIONS Voltage by areas 110V 220V 230V 240V Power input 690 W Speed change No load speed Capacity 1 2 Forward rotation 0 1000 min 1 0 3000 min Reverse rotation 0 600 min 1 0 1800 min Steel 13 mm 8 mm Concrete 18 mm 13 mm Wood Full load impact rate 40 mm 25 mm 8400 min 27300 min 1 Weight without cord 2 0 kg Be sure to check the nameplate on product as it is subject to change by areas STANDARD ACCESSORIES 1 Chuck Wrench Spec only for keyed chuck 1 2 Side Handle 1 3 Depth Gauge 1 Standard accessories are subject to change without notice OPTIONAL ACCESSORIES sold separately 1 Impact Drill Bit for concrete 3 2 mm 18 mm dia Optional accessories are subject to change without notice However when drilling 6 5 mm or smaller holes use a metalworking drill bit 5 Mounting and dismounting of the bit For keyed chuck Fig 1 1 Open the chuck jaws and insert the bit into the chuck 2 Place the chuck wrench in each of the three holes in the chuck and turn it in the clockwise direction viewed from the front side Tighten securely 3 To remove the bit place the chuck wrench into one of the holes in the chuck and turn it in the counterclockwise direction For keyless chuck fig 2 APPUCATIONS O By combined actions of ROTATION and IMPACT Boring holes in hard materials concrete marble granite tiles etc O By ROTATIONAL action Boring holes in metal wood and plastic PRIOR TO OPERATION 1 Power source Ensure that the power source to be utilized conforms to the power requirements specified on the product nam eplate 2 Power switch Ensure that the power switch is in the OFF position If the plug is connected to a receptacle while the power switch is in the ON position the power tool will start operating immediately inviting serious accident 3 Extension cord When the work area is removed from the power source use an extension cord of sufficient thickness and rated capacity The extension cord should be kept as short as practicable 4 Selecting the appropriate drill bit O When boring concrete or stone Use the drill bits specified in theOptional Accessories O When boring metal or plastic Use an ordinary metalworking drill bit O When boring wood Use an ordinary woodworking drill bit 1 Mounting the bit Turn the sleeve counterclockwise and open the chuck After inserting the drill bit into the chuck as far it will go grip the retaining ring and close the chuck by turning the sleeveclockwise as viewed from thefront 2 Dismounting the bit Grip the retaining ring and open the chuck by turning the sleeve counterclockwise NOTE When the sleeve does not become loose any further fix the side handleto retaining ring hold side handle firmly then turn thesleeveto loosen by hand Fig 3 6 Check the rotational direction Fig 4 The bit rotates clockwise viewed from the rear side by pushing the R side of the push button The L sideof the push button is pushed to turn the bit counterclockwise The D and CFO m arks are provided on the body CAUTION Always use the impact drill with clockwise rotation when using it as an impact drill 7 Fixing the side handle Rg 5 Attach the side handle to the mounting part Rotate the side handle grip in a clockwise direction to secure it Set the side handle to a position that is suited to the operation and then securely tighten the side handle grip To attach a depth gauge on the side handle insert the gauge into the U shaped groove on the side handle adjust the position of the depth gauge in accordance with the desired depth of the hole and firmly tighten the side handle grip Rg 6
