56D-Link DAP-1155 User Manual

Section 4 - Security

Using Windows

It is recommended to enable wireless security (WPA/WPA2) on your wireless router or access point before conguring your

wireless adapter. If you are joining an existing network, you will need to know the security key or passphrase being used.

1. Click on the wireless icon in your system tray (lower-right corner).

2. The utility will display any available wireless networks in your area.

Connect to a Wireless Network

Wireless Icon
