D-Link DAP-1155 [16/80] Bridge mode

16D-Link DAP-1155 User Manual

Section 3 - Conguration

This Wizard is designed to assist you in conguring your DAP-1155 as a wireless client.

Select WPS to connect using WPS (Wi-Fi Protected

Setup) and then click Next.

Bridge Mode

Enter the Device Name of the AP and click Next to

continue. It is recommended to change the Device

Name if there is more than one D-Link device within the

same wireless network.

Select Bridge from the drop-down menu.
