D-Link DAP-1155 [7/80] Hardware overview

7D-Link DAP-1155 User Manual

Section 1 - Product Overview

Hardware Overview

LEDs

Power LED: A solid light indicates

a proper connection to the power

supply and the Ethernet port. A

blinking light indicates Ethernet

disconnection.

Wireless LED: A solid light indicates that the

wireless segment is ready. This LED blinks

during wireless data transmission.

WPS LED: A solid light indicates a

successful WPS connection. A blinking

light indicates the device is trying to

establish a connection.
