DIS-200G Series Industrial Gigabit Ethernet Smart Managed Switch

Firmware Backup to HTTP

This window is used to initiate a firmware backup to a local PC using HTTP.

To view the following window, click Tools > Firmware Upgrade & Backup > Firmware Backup to

HTTP, as shown below:

The fields that can be configured are described below:

Parameter

Description

Source

Specify the firmware image ID to be backup.

Click the Backup button to initiate the firmware backup.

Firmware Backup to TFTP

This window is used to initiate a firmware backup to a TFTP server.

To view the following window, click Tools > Firmware Upgrade & Backup > Firmware Backup to TFTP,

as shown below:

Figure 3-5 Firmware Backup to HTTP window

Figure 3-6 Firmware Backup to TFTP window
