DIS-200G Series Industrial Gigabit Ethernet Smart Managed Switch

The fields that can be configured are described below:

Parameter Description

TFTP Server IP

Enter the TFTP server’s IPv4 address here.

Destination File

Enter the destination filename and path where the configuration

file should be stored on the TFTP server. This field can be up to 64

characters long.

Click the Backup button to initiate the configuration file backup.

Log Backup

Log Backup to HTTP

This window is used to initiate a system log backup to a local PC using HTTP.

To view the following window, click Tools > Log Backup > Log Backup to HTTP, as shown below:

Click the Backup button to initiate the system log backup.

Log Backup to TFTP

This window is used to initiate a system log backup to a TFTP server.

To view the following window, click Tools > Log Backup > Log Backup to TFTP, as shown below:

The fields that can be configured are described below:

Parameter

Description

TFTP Server IP

Enter the TFTP server’s IPv4 address here.

Destination File

Enter the destination filename and path where the log file should

be stored on the TFTP server. This field can be up to 64

characters long.

Click the Backup button to initiate the system log backup.

Figure 3-11 Log Backup to HTTP window

Figure 3-12 Log Backup to TFTP window
