DIS-200G Series Industrial Gigabit Ethernet Smart Managed Switch

Asymmetric VLAN

This window is used to configure the asymmetric VLAN function.

To view the following window, click L2 Features > VLAN > Asymmetric VLAN, as shown below:

The fields that can be configured are described below:

Parameter

Description

Asymmetric VLAN State

Select this option to enable or disable the asymmetric VLAN

function

Click the Apply button to accept the changes made.

VLAN Interface

This window is used to view and configure VLAN interface settings.

To view the following window, click L2 Features > VLAN > VLAN Interface, as shown below:

Click the View Detail button to view more detailed information about the VLAN on the specific interface.

Click the Edit button to re-configure the specific entry.

Figure 6-8 Asymmetric VLAN window

Figure 6-9 VLAN Interface window
