DIS-200G Series Industrial Gigabit Ethernet Smart Managed Switch

This window is used to configure the description, and display the PoE status of each port.

To view the following window, click System > PoE > PoE Status, as shown below:

PoE Configuration

This window is used to configure the PoE port.

To view the following window, click System > PoE > PoE Configuration, as shown below:

The fields that can be configured are described below:

Parameter Description

From Port / To Port Select the appropriate port range used for the configuration here.

Priority Select the priority for provisioning power to the port. Options to

choose from are Critical, High and Low.

Mode Select the power management mode for the PoE ports. Options to

choose from are

Auto

and Never.

Time Profile Select the name of the time range to determine the activation

period.

Click the Delete Time Profile button to clear the setting in the corresponding Time Range field.

Figure 4-8 PoE Status window

Figure 4-9 PoE Configuration window
