DIS-200G Series Industrial Gigabit Ethernet Smart Managed Switch

The fields that can be configured for Storm Control Settings are described below:

Parameter Description

Type

Select the type of storm attack that will be controlled here. Options

to choose from are Broadcast, Multicast, and Unicast. When the

action is configured as the shutdown mode, the unicast refers to

both known and unknown unicast packets; that is, if the known and

unknown unicast packets hit the specified threshold, the port will

be shutdown. Otherwise, unicast refers to unknown unicast

packets.

Status

Select to enable or disable the storm control feature for selected

type.

PPS Rise

Enter the rise packets per second value here. This option specifies

the rise threshold value in packets count per second. This value

must be between 1 and 1024000 packets per second.

Click the Apply button to accept the changes made.

DoS Attack Prevention Settings

This window is used to view and configure the Denial-of-Service (DoS) attack prevention settings. The

following well-known DoS types which can be detected by most switches:

• Land Attack: This type of attack involves IP packets where the source and destination address

are set to the address of the target device. It may cause the target device to reply to itself

continuously.

• Blat Attack: This type of attack will send packets with the TCP/UDP source port equal to the

destination port of the target device. It may cause the target device to respond to itself.

• TCP-Null: This type of attack involves port scanning by using specific packets which contain a

sequence number of 0 and no flags.

• TCP-Xmas: This type of attack involves port scanning by using specific packets which contain

a sequence number of 0 and the Urgent (URG), Push (PSH), and FIN flags.

• TCP SYN-FIN: This type of attack involves port scanning by using specific packets which

contain SYN and FIN flags.

• TCP SYN SrcPort Less 1024: This type of attack involves port scanning by using specific

packets which contain source port 0 to 1023 and SYN flag.

• Ping Death Attack: A ping of death is a type of attack on a computer that involves sending a

malformed or otherwise a malicious ping to a computer. A ping is normally 64 bytes in size

(many computers cannot handle a ping larger than the maximum IP packet size) which is

65535 bytes. The sending of a ping of this size can crash the target computer. Traditionally, this

bug has been relatively easy to exploit. Generally, sending a 65536 byte ping packet is illegal

according to networking protocol, but a packet of such a size can be sent if it is fragmented;

when the target computer reassembles the packet, a buffer overflow can occur, which often

causes a system crash.

• All Types: All of above types.
