DIS-200G Series Industrial Gigabit Ethernet Smart Managed Switch

Jumbo Frame

This window is used to view and configure the Jumbo Frame size and settings. The Switch supports

jumbo frames. Jumbo frames are Ethernet frames with more than 1,518 bytes of payload. The Switch

supports jumbo frames with a maximum frame size of up to 9600 bytes.

To view the following window, click System > Port Configuration > Jumbo Frame, as shown below:

The fields that can be configured are described below:

Parameter

Description

From Port / To Port

Select the appropriate port range used for the configuration here.

Maximum Receive Frame Size

Enter the maximum receive frame size value here. This value must

be between 1518 and 9600 bytes. By default, this value is 1518

bytes.

Click the Apply button to accept the changes made.

Figure 4-6 Jumbo Frame window
