DIS-200G Series Industrial Gigabit Ethernet Smart Managed Switch

Effective immediately

(running-config)

Specify this radio button to restore and overwrite the running

configuration file on the Switch.

Take effect after the next boot

(startup-config)

Specify this radio button to restore and overwrite the start-up

configuration file on the Switch.

Click the Restore button to initiate the configuration restore.

Configuration Backup to HTTP

This window is used to initiate a configuration file backup to a local PC using HTTP.

To view the following window, click Tools > Configuration Restore & Backup > Configuration Backup

to HTTP, as shown below:

The fields that can be configured are described below:

Parameter Description

Include Username Password

Specify this radio button to back up the running configuration file

include username password from the Switch.

Exclude Username Password

Specify this radio button to back up the running configuration file

exclude username password from the Switch.

Click the Backup button to initiate the configuration file backup.

Configuration Backup to TFTP

This window is used to initiate a configuration file backup to a TFTP server.

To view the following window, click Tools > Configuration Restore & Backup > Configuration Backup

to TFTP, as shown below:

Figure 3-9 Configuration Backup to HTTP window

Figure 3-10 Configuration Backup to TFTP window
