PictBridge Printing
121
4
D Secure the USB cable using the hook.
E On your digital camera, select the images you want to print, and specify the
printing conditions.
F The printer receives settings from the digital camera and starts printing.
Note
❒ Since printing conditions are specified on the digital camera, specifiable
parameters depend on the particular digital camera. For details, see the
digital camera's manual.
❒ Some digital cameras require settings for manual PictBridge operation. For
details, see your digital camera's manual.
Reference
To stop data printing, see p.108 “Canceling a Print Job”.
AQC049S
