Monitoring and Configuring the Printer
228
6
psk “character string” You can specify the Pre-Shared key.
Usable characters: ASCII 0x20-0x7e (8 to 63
bytes).
The default is blank.
eap {tls|ttls|leap|peap} {chap|msc-
hap|mschapv2|pap|md5|tls}
You can specify the EAP authentication type.
tls: EAP-TLS (default)
ttls: EAP-TTLS
leap: LEAP
peap: PEAP
chap, mschap, mschapv2, pap, md5, or tls
are settings for the phase 2 method, and
must be set when using EAP-TTLS or PEAP.
Do not make these settings when using other
EAP authentication types.
If you select EAP-TTLS, you can select chap,
mschap, mschapv2, pap, or md5.
If you select PEAP, you can select mschapv2
or tls.
username “character string” You can specify the login user name for the
Radius server.
Usable characters: ASCII 0x20-0x7e(31 bytes)
other than “@”. The default is blank.
username2 “character string” You can specify the phase 2 username for
EAP-TTLS/PEAP phase 2 authentication.
Usable characters: ASCII 0x20-0x7e (31
bytes) other than “@”. The default is blank.
domain “character string” You can specify the login domain name for
the Radius server.
Usable characters: ASCII0x20-0x7e (31 bytes)
other than “@”. The default is blank.
password "character string" You can specify the login password for the
Radius server.
Usable characters: ASCII 0x20-0x7e(128
bytes). The default is blank.
srvcert {on|off} You can set the server certificate. The default
is “off”.
imca {on|off} You can enable or disable the certificate
when the intermediate certificate authority is
present. The default is “off”.
srvid “character string” You can set the server ID and subdomain of
the certificate server.
Parameter Value configured
