Other Print Operations
112
3
Collate
The Collate function allows you to print while sorting printouts into page-or-
dered sets, such as when printing multiple copies of meeting materials.
Important
❒ To use these functions, an optional memory unit of at least 256 MB or the op-
tional hard disk drive must be installed on the printer.
❒ Up to 150 pages can be sorted using RAM. If the optional hard disk drive is
installed, up to 1,000 pages can be sorted.
❖ Collate
Output can be assembled as sets in sequential order.
Note
❒ If Auto Continue occurs on the first set, Collate will be canceled.
❒ If forced printing occurs on the first set, Collate will be canceled.
❒ When setting Collate in the printer driver settings, make sure that a collate
option is not selected in the application's print settings. If a collate option is
selected, printing will not be as intended.
Reference
For details about printing method, see the printer driver Help.
