Getting Printer Information over the Network
233
6
Key Card/Counter not inserted The printer is waiting for key card or key
counter to be inserted.
Key Counter not inserted
The printer is waiting for key counter to be left in it.
Loading Toner... Toner is being supplied.
Low: Black Toner The black toner cartridge is not set correctly, or
toner is almost running out.
Low: Cyan Toner The cyan toner cartridge is not set correctly, or
toner is almost running out.
Low: Magenta Toner The magenta toner cartridge is not set correct-
ly, or toner is almost running out.
Low: Toner The black toner cartridge is not set correctly, or
toner is almost running out.
Low: Yellow Toner The yellow toner cartridge is not set correctly,
or toner is almost running out.
Malfunction: Booklet Processor There is a problem with booklet finisher.
Malfunction: Ext. Charge Unit There is a problem with external charge unit.
Malfunction: Finisher There is a problem with Finisher.
Malfunction: Interposer There is a problem with Interposer.
Malfunction: Output Tray There is a problem with output tray.
Malfunction: Staple Unit There is a problem with the staple unit.
Malfunction: Tray 1 There is a problem with tray 1.
Malfunction: Tray 2 There is a problem with tray 2.
Malfunction: Tray 3 There is a problem with tray 3.
Malfunction: Z-folding unit There is a problem with the Z-fold unit.
Memory Low: Copy Memory shortage has occurred while the copy
was operating.
Memory Low: Data Storage Memory shortage has occurred while the doc-
ument was being accumulated.
Memory Low: Fax Scanning Memory shortage has occurred while trans-
mitting the fax.
Memory Low: Scanning Memory shortage has occurred while the scan-
ner was working.
Miscellaneous Error Other error has occurred.
Mismatch: Paper Size Indicated paper tray does not contain paper of
selected size.
Mismatch: Paper Size and Type Indicated paper tray does not contain paper of
selected size and type.
Mismatch: Paper Type Indicated paper tray does not contain paper of
selected type.
Near Replacing: Black PCU Prepare the new black photoconductor unit.
Messages Description
