Monitoring and Configuring the Printer
234
6
Near Replacing: Color PCU Prepare the new color photoconductor unit.
Near Replacing: Develop. Unit C Prepare the new development unit (cyan).
Near Replacing: Develop. Unit K Prepare the new development unit (black).
Near Replacing: Develop. Unit M Prepare the new development unit (magenta).
Near Replacing: Develop. Unit Y Prepare the new development unit (yellow).
Near Replacing: Fusing Unit Prepare the new fusing unit.
Near Replacing: Maintenance Kit Prepare the new maintenance kit.
Near Replacing: Transfer Unit Prepare the new transfer unit.
Nearly Full: Waste Toner Waste toner bottle is nearly full.
Need more Staples Stapler has almost run out of staples.
No Paper: Interposer Tray There is no paper in interposer unit.
No Paper: Selected Tray There is no paper in specified tray.
No Paper: Tray 1 There is no paper in tray 1.
No Paper: Tray 2 There is no paper in tray 2.
No Paper: Tray 3 There is no paper in tray 3.
Not Detected: B2 Lever B2 lever is not correctly set.
Not Detected: Black Toner Black toner is not correctly set.
Not Detected: Cyan Toner Cyan toner is not correctly set.
Not Detected: Develop. Unit (C) The development unit (cyan) is not correctly set.
Not Detected: Develop. Unit (K) The development unit (black) is not correctly set.
Not Detected: Develop. Unit (M) The development unit (magenta) is not cor-
rectly set.
Not Detected: Develop. Unit (Y) The development unit (yellow) is not correctly set.
Not Detected: Duplex Feed Unit The duplex feed unit is not correctly set.
Not Detected: Finisher Finisher is not correctly set.
Not Detected: Fusing Unit The fusing unit is not correctly set.
Not Detected: Input Tray The paper feed tray is not correctly set.
Not Detected: Interposer Interposer unit is not correctly set.
Not Detected: Magenta Toner Magenta toner is not correctly set.
Not Detected: PCU (C)
The photoconductor unit (cyan) is not correctly set.
Not Detected: PCU (K)
The photoconductor unit (black) is not correctly set.
Not Detected: PCU (M)
The photoconductor unit (magenta) is not correctly
set.
Not Detected: PCU (Y)
The photoconductor unit (yellow) is not correctly
set.
Not Detected: Transfer Unit The transfer unit is not correctly set.
