Making Printer Settings Using the Control Panel
162
5
❖ PDF Menu
You can set conditions when using PDF printing.
❖ Change PDF Password
You can specify the password for the PDF file executing PDF Direct Print.
Important
❒ If you do not set a PDF password, this menu does not appear.
Note
❒ The password can be set using Web Image Monitor, but must be sent
through the network. For increased security, use this menu on the con-
trol panel to set the password directly.
❖ PDF Group Password
You can set a group password specified using DeskTopBinder Lite.
Important
❒ If you do not set a PDF group password, this menu does not appear.
Note
❒ When you use a group password, the optional data protection unit must
be installed.
❒ The password can be set using Web Image Monitor, but must be sent
through the network. For increased security, use this menu on the con-
trol panel to set the password directly.
❒ Default: no password set
❖ Resolution
You can select the resolution for the PDF file executing PDF Direct Print.
• 600dpi Fast
• 600dpi Standard
• 1200dpi
Note
❒ Default: 600dpi Fast
❖ Colour Setting
You can make an RGB setting for the PDF file executing PDF Direct Print.
•None
•Fine
•Super Fine
Note
❒ Default: Super Fine
