Monitoring and Configuring the Printer
224
6
❖ SSH/SFTP communication timeout setting
msh> ssh timeout {0–65535}
The default is 300.
❖ SSH/SFTP communication login timeout setting
msh> ssh logintimeout {0–65535}
The default is 300.
❖ Setting an open key for SSH/SFTP
msh> ssh genkey {512|768|1024} "character string"
Create an open key for SSH/SFTP communication.
Usable characters are ASCII 0x20-0x7e (32 bytes) other than “0”.
The default key length is 1024, and the character string is blank.
❖ Deleting open key for ssh/sftp communication
msh> ssh delkey
Note
❒ If you do not specify a character string, current setting is displayed.
status
Use the “status” command to display the printer status.
❖ Messages
msh> status
Reference
For details, see p.231 “Current Printer Status”.
syslog
Use the “syslog” command to display the information stored in the printer's sys-
tem log.
❖ View message
msh> syslog
Note
❒ For details about the information displayed, see p.246 “System Log Informa-
tion”.
