Ricoh Aficio SP C411DN [176/354] Changing the security options menu
![Ricoh Aficio SP C411DN [176/354] Changing the security options menu](/views2/1064420/page176/bgb0.png)
Making Printer Settings Using the Control Panel
164
5
Security Options Menu
You can specify security settings.
Depending on the security settings, certain items may not be displayed.
Changing the Security Options menu
Follow the procedure below to change the Erase All Memory.
A Press the {Menu} key.
The menu appears.
B Press the {U} or {T} key to display [Security Options], and then press the {OK} key.
C
Press the
{U}
or
{T}
key to display
[
Extended Security
]
, and then press the
{
OK
}
key.
D
Press the
{U}
or
{T}
key to display
[
Erase All Memory
]
, and then press the
{
OK
}
key.
E Press the {U} or {T} key to select the erase method, and then press the {OK} key.
When you select [Random Numbers], enter overwrite times.
All memories will be erased.
F When the confirmation screen appears, press the {Exit} key.
Message appears.
G Turn off the power.
Security Options menu parameters
This section explains parameters that can be set on the Security Options menu.
❖ Extended Security
❖ Driver Encryption Key
You can specify the driver encryption key.
❖ Encrypt Address Book
You can select whether or not to encrypt the data in the address book.
AQC001S
YMCK
