Security Options Menu
165
5
❖ Service Mode Lock
You can select whether or not to enter into service mode.
•On
•Off
Note
❒ Default: Off
❖ Firmware Version
Displays the firmware version installed on this printer.
❖ Network Security Level
You can specify the network level.
• Level 0
• Level 1
• Level 2
Note
❒ Default: Level 0
❖ Auto Erase Memory Setting
This function is available when the Optional Overwrite Security Unit is in-
stalled. Selects whether or not to automatically delete memory, and select de-
letion method and time when you do.
•On
HD Erase Method: NSA, DoD, Random Numbers
No. of Overwrites: between 1 - 9
•Off
❖ Erase All Memory
Deletes all data inside the memory. Select the deletion method, and then set
the overwrite times.
❖ HD Erase Method
•NSA
•DoD
• Random Numbers
❖ No. of Overwrites
between 1 - 9
❖ Transfer Log Setting
You can select whether or not to send the log.
• On (Only available from the log collection server.)
•Off
Note
❒ Default: Off
