Printer Utility for Mac
307
9
Printing Font Catalog
You can print the names of fonts available on the printer.
A Select [Print Fonts Catalog...] on the [File] menu.
B Click [Print].
Note
❒ The paper selected under [Page Setup] is used.
Printing Font Sample
You can print samples of fonts downloaded to the hard disk drive or memory.
A Select [Print Fonts Sample...] on the [File] menu.
B Click [Print].
Note
❒ Print by using the paper selected on [Page Setup].
Renaming the Printer
You can change the printer name displayed under Appletalk. If you connect sev-
eral printers on the network, assign different names so you can identify them. If
several printers have the same name, a digit appears next to the printer name in
[Chooser].
Important
❒ You can enter up to 31 digits and letters.
❒ Do not use symbols, for example “*”, “:”, “=”, “@”, “~”.
Mac OS
A On the [File] menu, click [Rename Printer...].
B In the [New Name:] filed enter a new name.
C Click [Rename].
The printer name is changed.
D Click [OK].
E On the Apple menu, click [Chooser].
F Click the [AdobePS] icon.
G Select the printer whose name you changed, and then close the [Chooser] di-
alog box.
If there are several AppleTalk zones, select the zone the printer belongs to.
