Remote Maintenance by telnet
227
6
keyphrase “ phrase” val {1|2|3|4} You can specify the WEP key when entering
in ASCII.
With a 64-bit WEP, you can use 10 digit hex-
adecimals. With a 128-bit WEP, you can use
26 digit hexadecimals.
Up to four WEP keys can be registered. Spec-
ify the number to be registered with “val”.
When a WEP is specified by key phrase, the
WEP specified by key is overwritten.
To use this function, set the same key
number and WEP key for all ports that trans-
mit data to each other.
You can omit the numbers with “val”. The
key number is set to 1 when making these
omissions.
encval {1|2|3|4} You can specify which of the four WEP keys
is used for packet encoding. “1” is set if a
number is not specified.
wepauth [open|shared] You can set an authorization mode when us-
ing WEP. The specified value and authorized
mode are as follows:
open: open system authorized (default)
shared: shared key authorized rate
rate [auto|11m|5.5m|2m|1m] You can set the IEEE 802.11b transmitting
speed.
The speed you specify here is the speed at
which data is sent. You can receive data at
any speed.
auto: automatically set (default)
11m: 11 Mbps fixed
5.5m: 5.5 Mbps fixed
2m:2 Mbps fixed
1m: 1 Mbps fixed
security {none|wep|wpa} You can specify the security mode.
none: No encryption(default)S
wep: WEP encryption
wpa: WPA encryption
wpaenc {tkip|ccmp} You can specify WPA encryption key when
using WPA encryption.
tkip: TKIP (default)
ccmp: CCMP (AES)
wpaauth {wpapsk|wpa} You can specify the WPA authentication
mode when using WPA encryption.
wpapsk: WPA-PSK authentication(default)
wpa: WPA(802.1X) authentication
Parameter Value configured
