Appendix
326
11
❖ For DHCP settings
As a substitute for the printer, the DHCP server updates the record, and one
of the following occurs:
• When the printer acquires the IP address from the DHCP server, the
DHCP server updates the A and PTR records.
• When the printer acquires the IP address from the DHCP server, the print-
er updates the A record, and the DHCP server updates the PTR record.
If the A record is registered, CNAME is also registered. CNAMEs that can be
registered are as follows:
• Ethernet and IEEE 802.11b
RNPXXXXXX (XXXXXX represents the last 3 hexadecimal bytes of the
MAC address)
Important
❒ Dynamic update using message authentication (TSIG, SIG(0)) is not supported.
DNS servers targeted for operation
❖ For static IP setting
• Microsoft DNS servers with standard Windows 2000 Server/Windows
Server 2003 features
• BIND 8.2.3 or higher
❖ For DHCP setup, when the printer updates the A record
• Microsoft DNS servers with standard Windows 2000 Server/Windows
Server 2003 features
• BIND 8.2.3 or higher
❖ For DHCP setup, when the DHCP server updates records
• Microsoft DNS servers with standard Windows 2000 Server/Windows
Server 2003 features
• BIND 8.2.3 or higher
• DNS servers with standard NetWare 5 (or a higher version) features
DHCP servers targeted for operation
As a substitute for the printer, DHCP servers capable of updating the A record
and PTR record are as follows:
• Microsoft DHCP servers with standard Windows 2000 Server (Service Pack 3
or higher versions)/Windows Server 2003 features
• ISC DHCP 3.0 or higher
• DHCP server with standard NetWare 5 features
Setting the dynamic DNS function
Make settings with telnet using the “dns” command. For details, see p.206
“dns”.
