Making Printer Settings Using the Control Panel
154
5
❖ Memory Usage
You can select memory to be used from "Font Priority" or "Frame Priority".
• Font Priority
•Frame Priority
Note
❒ Default : Frame Priority
❖ B&W Page Detect
Specify whether to recognize black-and-white images. Use the black-and-
white recognition function to print all monochrome pages in monochrome
mode even if color printing is specified.
•Per Page
•Per Job
Note
❒ Default: Per Page
❖ Spool Printing
You can select whether all of the print data is spooled to the hard disk drive
before printing.
•On
•Off
Note
❒ Default: Off
❒ Spooling stores a sent print job temporarily in the printer, and then prints it.
❒ This menu appears only when the optional hard disk is installed.
❖ RAM Disk
If the optional hard disk is not installed for PDF Direct Print, select a value of
2 MB or higher.
This menu appears only when the optional hard disk is not installed.
•0 MB
•2 MB
•4 MB
•8 MB
• 16 MB
Note
❒ Default: 4 MB
Important
❒ When the amount of SDRAM is small and RAM Disk is set to 16 MB, print-
ing may not be possible depending on the print job and duplex printing
may be canceled. If this happens, increase the amount of SDRAM, or set
RAM Disk to 8 MB or less.
Reference
For details about the optional SDRAM module, see Hardware Guide.
