Ricoh Aficio SP C411DN [220/354] Hostname
![Ricoh Aficio SP C411DN [220/354] Hostname](/views2/1064420/page220/bgdc.png)
Monitoring and Configuring the Printer
208
6
❖ Interface domain configuration
msh> domainname “interface_name”
❖ Setting the Domain Name
msh> domainname “interface_name” name “domain name”
• A domain name can be entered using up to 63 alphanumeric characters.
• The Ethernet interface and IEEE 802.11b interface will have the same domain name.
• wlan can be specified only when the IEEE 802.11b interface is installed.
❖ Deleting the Domain Name
msh> domainname “interface_name” clear name
help
Use the “help” command to display the available command list and the proce-
dures for using those commands.
❖ Command list display
msh> help
❖ Display of procedure for using commands
msh> help “command_name”
hostname
Use the “hostname” command to change the printer name.
❖ View settings
msh> hostname
❖ IPv4 Configuration
msh> hostname “interface_name ” “printer_name”
• Enter the printer name using up to 63 alphanumeric characters.
• You cannot use a printer name starting with “RNP” or “rnp”.
• The Ethernet interface and IEEE 802.11b interface will have the same printer name.
• wlan can be specified only when the IEEE 802.11b interface is installed.
Interface Interface set
ether Ethernet interface
wlan IEEE 802.11b interface
Interface name Interface configured
ether Ethernet interface
wlan IEEE 802.11b interface
