Using a Printer Server

262

M As type, select [Remote Parallel, LPT1].

The IRQ, Buffer size, Starting form, and Queue service mode are automatical-

ly configured.

N Press the {Esc} key, and then click [Yes] on the confirmation message.

O Press the {Esc} key to return to [Print Server Configuration Menu].

P Assign print queues to the created printer.

Q From [Print Server Configuration Menu], select [Queues Serviced By Printer].

R Select the printer created.

S Press the {Insert} key to select a queue serviced by the printer.

You can select several queues.

T Follow the instructions on the screen to make other necessary settings.

Following these steps, check that the queues are assigned.

U Press the {Esc} key until “Exit?” appears, and then select [Yes] to exit

PCONSOLE.

V Start the print server by entering the following from the console of the Net-

Ware server.

If the print server is in operation, quit and restart it.

❖ To quit

CAREE: unload pserver

❖ To start

CAREE: load pserver “print_server_name”

Note

❒ If the printer works as configured, the message “Waiting for job” appears.

Setting up using Web Image Monitor

A Start Web Image Monitor.

B Click [Login].

A dialog box for entering the [Login User Name] and [Login Password] appears.

C Enter the login user name and password, and then click [Login].

For details about the login name and password, consult your network admin-

istrator.

D Click [Configuration] in the left area, and then click [NetWare].
