Remote Maintenance by telnet
219
6
snmp
Use the “snmp” command to display and edit SNMP configuration settings such
as the community name.
❖ View settings
msh> snmp
• Default access settings 1 is as follows:
Community name:public
IPv4 address:0.0.0.0
IPv6 address:::
IPX address:00000000:000000000000
Access type:read-only
Effective Protocol:IPv4/IPv6/IPX
• Default access settings 2 is as follows:
Community name:admin
IPv4 address:0.0.0.0
IPv6 address:::
IPX address:00000000:000000000000
Access type:read-write
Effective Protocol:IPv4/IPv6/IPX
• If "-p" is added, you can view settings one by one.
• To display the current community, specify its registration number.
❖ Display
msh> snmp ?
❖ Community name configuration
msh> snmp “number” name “community_name”
• You can configure ten SNMP access settings numbered 1-10.
• The printer cannot be accessed from SmartDeviceMonitor for Admin or
SmartDeviceMonitor for Client if “public” is not registered in numbers 1-
10. When changing the community name, use SmartDeviceMonitor for
Admin and SNMP Setup Tool to correspond with printer settings.
• The community name can be entered using up to 15 characters.
❖ Deleting community name
msh> snmp “number” clear name
