Remote Maintenance by telnet
215
6
Note
❒ The maximum number of IPv4 routing tables is 16.
❒ The maximum number of IPv6 routing tables is 2.
❒ Set a gateway address when communicating with devices on an external net-
work.
❒ The same gateway address is shared by all interfaces.
❒ “Prefixlen” is a number between 1 and 128.
set
Use the "set" command to set the protocol information display "active" or "inactive".
❖ View settings
The following command displays protocol information (active/inactive).
msh> set ipv4
msh> set ipv6
msh> set appletalk
msh> set netware
msh> set smb
msh> set protocol
• When protocol is specified, information about TCP/IP, AppleTalk, Net-
ware, SCSI print, PictBridge and SMB appears.
msh> set parallel
msh> set usb
msh> set bluetooth
msh> set lpr
msh> set lpr6
msh> set ftp
msh> set ftp6
msh> set rsh
msh> set rsh6
msh> set diprint
msh> set diprint6
msh> set web
msh> set snmp
msh> set ssl
msh> set ssl6
msh> set nrs
msh> set rfu
