Using the Standard TCP/IP Port
23
1
C Select an interface language, and then click [OK].
The default interface language is English.
D Click [PostScript 3 Printer Driver].
Add Printer Wizard starts.
E Click [Next >].
F Click [Local printer], and then click [Next >].
G Click [Create a new port:].
H Click [Standard TCP/IP Port], and then click [Next >].
I Click [Next >] in the [Add Standard TCP/IP Printer Port Wizard] dialog box.
J Enter the printer name or IPv4 address in the [Printer Name or IPv4 Address]
box, and then click [Next >].
When screen for Device selection appears, select “RICOH NetworkPrinter
Driver C Model”.
K Click [Finish] in the [Add Standard TCP/IP Printer Port Wizard] dialog box.
L Check that the name of the printer whose driver you want to install is se-
lected, and then click [Next >].
M Change the printer name if you want, and then click [Next >].
Select the [Yes] check box to configure the printer as default.
N Click [Next >].
O Specify whether or not to print a test page, and then click [Next>].
P Click [Finish].
The printer driver installation starts.
Note
❒ Auto Run may not work with certain operating system settings. If this hap-
pens, launch “Setup.exe” on the CD-ROM root directory.
❒ The printer driver with the selected language will be installed. The English
printer driver is installed when the following language is selected: Cestina,
Magyar, Polski, Portugues, Suomi.
❒ A User Code can be set after the printer driver installation . For informa-
tion about User Code, see the printer driver Help.
