Using the LPR Port
29
1
F Click [Local Printer attached to this computer.], and then click [Next >].
G Click [Create a new port:].
H Click [LPR Port] in [Create a new Port], and then click [Next >].
I Enter the printer's IP address in the [Name or address of server providing lpd] box.
J Enter “lp” in the [Name of printer or print queue on that server box], and then click [OK].
K Check that the name of the printer whose driver you want to install is se-
lected, and then click [Next >].
L Change the printer name if you want, and then click [Next >].
Select the [Yes] check box to configure the printer as default.
M Click [Next >].
N Specify whether or not to print a test page, and then click [Next >].
O Click [Finish].
The printer driver installation starts.
Note
❒ Auto Run may not work with certain operating system settings. If this hap-
pens, launch “Setup.exe” on the CD-ROM root directory.
❒ The printer driver with the selected language will be installed. The English
printer driver is installed when the following language is selected: Cestina,
Magyar, Polski, Portugues, Suomi.
❒ A User Code can be set after the printer driver installation. For information
about User Code, see the printer driver Help.
