Preparing for Printing
40
1
I Insert the printer driver. Click [Search for the best driver for your device. [Recom-
mended]], and then click [Next >].
J Select the [Specify a location:] check box, and then click [Browse...].
The [Browse for Folder] dialog box appears.
K Insert the CD-ROM into the CD-ROM drive.
When Auto Run starts, click [Exit].
L Specify the location where USB Printing Support is located, and then click
[Next >].
If the CD-ROM drive is D, the source files of USB Printing Support are stored
in the following location:
•RPCS
D:\DRIVERS\RPCS\WIN9X_ME\(Language)\DISK1
• PCL 5c (for colour printing)
D:\DRIVERS\PCL5C\WIN9X_ME\(Language)\DISK1
•PCL 6
D:\DRIVERS\PCL6\WIN9X_ME\(Language)\DISK1
• PostScript 3
D:\DRIVERS\PS\WIN9X_ME\(Language)\DISK1
M Check the location, and then click [Next >].
Add Printer Wizard starts.
N Click [Finish].
Installation is complete. If installation is successful, the icon of the printer
connected to the “USB001” port is added to the [Printers] window.
Note
❒ The number after “USB” varies depending on the number of printers con-
nected.
❒ It is not necessary to reinstall USB Printing Support when connecting a dif-
ferent printer via USB interface when USB Printing Support is installed.
❒ After installing USB Printing Support, if the printer driver is not installed,
follow the plug-and-play instructions of the printer.
❒ Install the printer driver from the CD-ROM provided with the printer.
