The Digital Controller ESIE07-04
2–40 Part 2 – Functional Description
3
1
2
4
5
2.4.6 Input / Output Menu
Operational
information
Using this menu you can read the inputs and outputs from the controller, software information and EEV
driver information.
I/O expansion
board
The screens below are only visible when the unit has economizer (units /A and /Z).
These screens show you the status of the digital output of the I/O expansion board.
Software This screen shows the software version installed in the controller.
Digital inputs and
outputs
This screen shows the status (O = open, C = closed) of the digital inputs and outputs.
Key :
Password : NO
Switching between
control board # 1 and # 2 :
P N : Economizer of this circuit is not active
P Y : Economizer of this circuit is active
I/O Exp E
DO 1 : Economizer # 1 N
DO 2 : Economizer # 2 N
I/O Exp E
DO 3 : Economizer # 3 N
DO 4 : Economizer # 4 N
Code : Air
V. 21.307 13/10/06
Digital Inputs
C C C C C C C C C C C C C C C C C C C C C C
Digital Outputs
O O O O O O O O O O O O O O O O O O O O O O
