![Daikin EWAD900BJYNN/A [250/346] Head pressure control](/views2/1660213/page250/bgfa.png)
Functional Control ESIE07-04
2–110 Part 2 – Functional Description
3
1
2
4
5
3.25 Head Pressure Control
3.25.1 Fan Management
Purpose To regulate the high pressure
There are 3 possible setting depending on the unit and options:
P Fan steps on/off management
P Phase cut fan management on all fans
P On/off fans + phase cut fan management
Function
description
In the controller, the fan management has to be specified. First of all the fan type and fan steps have
to be selected.
Explanation: enable
P None: not used
P Press: fan management is based on the high pressure of the unit
P Temp: not used
Type:
P VFD (variable fan drive) - when the unit is equipped with phase cut fans, this type of fan should be
selected.
P Steps - when the unit is equipped with on/off fans, this type of fan should be selected.
P Speedtr - when the unit is equiped with the option OPLA (Option Low Ambient), this type of fan
should be selected.
Fan steps:
According to the unit the number of fan steps has to be entered. This setting is only present when
the unit is equipped with on/off fans.
Condensation
Enable
Type
Fan Steps
Press.
Steps
1 - 4
