ESIE07-04 General Outline
Part 1 – System Outline 1–21
3
1
4
5
1.10 Electrical Specifications: EWAD-BJYNN
Electrical
specifications
The tabel below contains the electrical specifications
Notes:
(1) Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ± 3%.
(2) Nominal current is based on: 12/7 °C entering/leaving evaporator water temperature and 35°C ambient temp.
(3) Maximum current is based on: 14/9 °C entering/leaving evaporator water temperature and 44°C ambient temp.
(4) Inrush current of biggest compressor + 75 % of nominal absorbed current of the other compressor + fans
current.
(5) Compressor FLA + fans current.
Model EWAD-BJYNN
Unit size 650 700 750 850
Standard voltage (1) 400 V - 3f - 50 Hz
Nominal unit current (2) A 414 436 471 502
Max compressor current (3) A 435 460 501 542
Fans current A 36 40 44 48
Max unit current (3) A 471 500 545 590
Max unit inrush current (4) A 814 834 838 867
Max unit current for wires sizing (5) A 530 582 625 668
Model EWAD-BJYNN
Unit size 900 950 C10 C11 C12
Standard voltage (1) 400 V - 3f - 50 Hz
Nominal unit current (2) A 497 632 658 688 726
Max compressor current (3) A 548 664 687 730 773
Fans current A 48 56 64 64 72
Max unit current (3) A 596 720 751 794 845
Max unit inrush current (4) A 867 998 1022 1022 1055
Max unit current for wires sizing (5) A 668 821 877 916 963
Model EWAD-BJYNN
Unit size C13 C14 C15 C16 C18
Standard voltage (1) 400 V - 3ph - 50 Hz
Nominal unit current (2) A 756 744 938 1004 994
Max compressor current (3) A 816 820 1002 1084 1096
Fans current A 72 72 88 96 96
Max unit current (3) A 888 892 1090 1180 1192
Max unit inrush current (4) A 1079 1079 1284 1292 1292
Max unit current for wires sizing (5) A 1002 1002 1250 1336 1336
