The Digital Controller ESIE07-04
2–66 Part 2 – Functional Description
3
1
2
4
5
Condensation
setpoint
This screen is only visible if fan type VFD or SPEEDTR is selected (units option OPFS or OPLA).
This screen allows you to set the condensation setpoint.
Temperature
setpoint limits
This screen allows you to set the minimum and maximum setpoint limits.
Probes enable
screen
This screen allows you to enable or disable the analog inputs.
Remark : When using setpoint override (4-20 mA), probe B3 has to be enabled. When using demand
limit, probe B8 has to be enabled.
P Condensation Setpoint : Condensation setpoint for phase cut fans (VFD or SPEEDTR)
Condensation
Setpoint 09.0 bar
P Low : Minimum chilled outlet water temperature setpoint you can enter in the setting menu
(MOW)
P High : Maximum chilled outlet water temperature setpoint you can enter in the setting menu
ChLWT Temperature
Setpoint Limits
Low 04.0 ˚C
High 10.0 ˚C
P U : 1 : Analog inputs of control board # 1
P Bx : Y : Analog input x is enabled
P Bx : N : Analog input x is disabled
Probes enable U : 1
B1 : Y B2 : Y B3 : Y B4 : Y
B5 : Y B6 : Y B7 : Y B8 : Y
B9 : Y B10 : Y
