The Digital Controller ESIE07-04
2–46 Part 2 – Functional Description
3
1
2
4
5
Interstage timer This screen allows you to set the interstage time and the double pulse setpoint.
Pressure safety
prevention
These screens allow you to set the high and low pressure safety preventions.
High discharge
alarm
This screen allows you to set the discharge temperature alarm setpoint.
Remark : discharge temperature = delivery temperature (PT1000 sensor in oil separator)
Flow switch alarm This screen allows you to set the flow switch alarm delay timers.
P Interstage Time : Interstage time used for temperature regulation
P Double Pulse under : Double load pulses are given below setpoint
Interstage Time 0210 s
Double Pulse Under 035 %
P Cond. P. Hold : Condenser pressure hold capacity
P Cond. P. Down : Condenser pressure load down
P Evap. P. Hold : Evaporator pressure hold capacity
P Evap. P. Down : Evaporator pressure load down
Cond. P. Hold 016.5 bar
Cond. P. Down 017.5 bar
Cond. P. Hold 001.5 bar
Cond. P. Down 001.3 bar
Disch Temp Alarm
Setpoint 110.0 ˚C
P Start-Up Delay : When the flow switch is not closed for 20 seconds (default) during pump lead
time, alarm will be displayed
P Run Delay : When the flow switch is not closed for 5 seconds (default) during operation of
the unit, alarm will be displayed
Evaporat. Flow Alarm Delays
Start-Up Delay 20 s
Run Delay 05 s
