Daikin EWAD900BJYNN/A [161/346] Addressing of plan rs485
![Daikin EWAD900BJYNN/A [161/346] Addressing of plan rs485](/views2/1660213/page161/bga1.png)
ESIE07-04 The Digital Controller
Part 2 – Functional Description 2–21
3
2
4
5
1
2.3.6 Addressing of plan/RS485
To get the correct functionality of the pLAN net system, it is necessary to address correctly all the
installed components. Each component, as previously described, has a series of microswitches that
must be set as specified in the following table.
pLAN component Microswitch
123456
Local DISPLAY ON ON ON OFF OF OFF
Remote DISPLAY (if available) OFF OFF OFF ON OFF OFF
COMP. BOARD #1 ON OFF OFF OFF OFF OFF
COMP. BOARD #2 OFF ON OFF OFF OFF OFF
DRIVER EXV #1 ON ON OFF OFF OFF OFF
DRIVER EXV #2 OFF OFF ON OFF OFF OFF
DRIVER EXV #3 ON OFF ON OFF OFF OFF
DRIVER EXV #4 OFF ON ON OFF OFF OFF
RS485 component Microswitch
1234
EXP. BOARD #1 ON OFF ON OFF
