General Outline ESIE07-04
1–38 Part 1 – System Outline
3
1
1
4
5
1.23 Outlook Drawing: EWAD700BJYNN+OPTP, EWAD700BJYNN+OPRN+OPTP and
EWAD700BJYNN+OPLN+OPTP
The illustration below shows the outlook, the dimensions and the installation and service space of the
unit (mm).
(Frame)
(Control box)
Air discharge
See
detail B
Fan arrangements and minimum
clearance requirements
See detail A
Isolators location
Detail "A" rubber isolator
Fixing bolt (not furnished)
Refer
Detail B
''Victaulic''coupling-furnished
Connecting pipe-furnished
Concrete footing
I.D. 13 N. 4 holes
Optional right hand
evaporator water
Version Condenser Type
Weight KG
Type (q/ty)
786010-m
(5 Pz.)
Shipping Operating A B C D E F
1010 1090 885 945 925 9855630 5840
Isolators load KG
Aluminum
Acrylic coated
Rubber isolators
EWAD700BJYNN+OPTP
EWAD700BJYNN+OPRN+OPTP
EWAD700BJYNN+OPTP
EWAD700BJYNN+OPRN+OPTP
EWAD700BJYNN+OPLN+OPTP
1070 1150 945 1005 925 9855870 6080
Aluminum
Acrylic coated
EWAD700BJYNN+OPLN+OPTP
''Victaulic''coupling-furnished
Connecting pipe-furnished
