General Outline ESIE07-04
1–62 Part 1 – System Outline
3
1
1
4
5
1.35 Outlook Drawing: EWAD900BJYNN+OPPR, EWAD900BJYNN+OPPR+OPRN and
EWAD900BJYNN+OPPR+OPLN
The illustration below shows the outlook, the dimensions and the installation and service space of the
unit (mm).
(Frame)
(Control box)
Air discharge
See
detail B
Fan arrangements and minimum
clearance requirements
See detail A
Isolators location
Detail "A" rubber isolator
Fixing bolt (not furnished)
Refer
Detail B
''Victaulic''coupling-furnished
Connecting pipe-furnished
Concrete footing
I.D. 13 N. 4 holes
Optional right hand
evaporator water
Version Condenser Type
Weight KG
Type (q/ty)
786010-m
(4 Pz.)
786011-h
(2 Pz.)
Shipping Operating A B C D E F
1080 1165 920 985 867 9175680 5834
Isolators load KG
Aluminum
Acrylic coated
Rubber isolators
EWAD900BJYNN+OPPR
EWAD900BJYNN+OPPR+OPRN
EWAD900BJYNN+OPPR
EWAD900BJYNN+OPPR+OPRN
EWAD900BJYNN+OPPR+OPLN
1140 1225 980 1045 867 9175920 6174
Aluminum
Acrylic coated
EWAD900BJYNN+OPPR+OPLN
