ESIE07-04 The Digital Controller
Part 2 – Functional Description 2–63
3
2
4
5
1
Global PID request This screen shows you the global PID request.
Remark : Only one action can be requested at a time.
Maintenance
password
This screen allows you to enter the maintenance password.
Maintenance
read-out menu on
control board # 2
(comp 3 and 4)
If compressor 3 or 4 is present, you can scroll between control board # 1 (comp 1 and 2) and control
board # 2 (comp 3 and 4).
When you press the info button, the following screens will appear for control board # 2 :
P Compressor running data screens for comp 3 (see page 2–61)
P Compressor running data screens for com 4 (see page 2–61)
P Maintenance password screen (see page 2–63)
P Load :
N : No load requested
Y : Load requested
P Unload :
N : No unload requested
Y : Unload requested
P Stand-by :
N : No stand-by requested
Y : Stand-by requested
Global PID Request
Load Y
Unload N
Stand-by N
Digit
maintenance password
