Functional Control ESIE07-04
2–116 Part 2 – Functional Description
3
1
2
4
5
3.28 Heat Recovery Microprocessor Set-up
Function
description
The unit supplied with the heat recovery condensers is equipped with an additional microprocessor
TC10 (see electric wiring diagram) with two, three or four steps to control the hot water temperature
according to the number of heat exchangers installed in the unit (one step for each compressor). For
reference on how to set this microprocessor, see the specific manual supplied with the unit.
Below are important setup values (for references, see the microprocessor manual):
Item Description Setpoint
St1 Inlet water temperature setpoint Max 50
St2 N/A
CO Operating Mode 1
P1 Differential Setpoint 2
P2 N/A
C4 Authority 0.5
C5 1
C6 0
C7 3
C8 5
C9 0
C10 0
C11 0
C12 20
C13 1
C14 0
C15 0
C16 100
C17 5
C18 0
C19 0
C21 30
C22 43
C23 N/A
C24 N/A
P25 8
P26 55
P27 2
P28 20
C29 4
C30 N/A
C31 0
C32 1
C33 0
C50 4
C51 0
